Oxynon®
The recent progress in material development in the field of Powder Metallurgy is
remarkable.
Sintering equipment is now required to have more precise control of atmosphere and temperature.
In response KYK developed the "OXYNON®" sintering furnace in 1999 which provides an ultra low oxygen partial pressure inside the furnace.
The "Carbon-Carbon composite belt" used for the "OXYNON®" furnace made possible a belt-conveyance at ultra high temperature up to 2500℃.
This unique "OXYNON®" is being used for the Next Stage such as brazing of aluminum
("OxynonCAB®), titanium, steel, stainless steel, etc.

Oxynon® Firing/Sintering Furnace

E-GRB-SIT
E-GRB-CAL

Features
● Oxygen partial pressure can be reduced to less than 5 ppm.
● No chromium loss with normal atmosphere pressure inside the furnace.
● Continuous conveyance and thermal treatment up to 2500℃ with the use of a C/C composite
    belt.
● Heat treatment in innert furnace atmospheres (argon or nitrogen) with no risk of explosion.
● Uniform temperature distribution within the furnace.
● Shorter processing time.
● Possible to optimize debinding process and exhaust gas treatment.
● Inhouse laboratory furance is available for clients' various testing with charge.
Main applications
● Sintering of steels, low alloy steels and high alloy steels. Firing and reaction sintering of
    ceramics. Heat dessociation of difficult-to-reduce metal oxides.
Main specifications
● Maximum Temperature: 2500℃
● Atmosphere: Nitrogen, Argon
● Belt width: 150 - 650mm

OxynonCAB®Mesh belt Aluminum brazing Furnace

E-MES-NOC

Features
● Excellent brazability due to the low oxygen partial pressure in the furnace.
● Hearth surface can be maintained flat with more than 1500mm wide mesh belt.
● A radiation-heating preheating furance provides quick heating.
● Uniform temperature distribution within the furnace.
● Short start-up time.
● Capable of setting different temperatures between the top zone and botton zone in the
　 furnace.
● Applicable from laboratory to production scale equipment, exceeding the capacity of large
　 scale metal muffle furnace.
● Inhouse laboratory furnace is available for clients' preliminary study of production
　 requirements (fee based).
Main applications
● Brazing of aluminum made heat exchangers and functional components.
Main specifications
● Maximum Temperature: 620℃
● Atmosphere: Nitrogen
● Capacity: Laboratory scale up to a large mass production scale
　 (the widest ever built was 2300mm wide).

OxynonCAB®Roller hearth Aluminum brazing Furnace

E-ROL-NOC

Features
● Roller hearth design reduces energy consumption compared to belt furnace.
● Excellent brazability due to the low oxygen partial pressure in the furnace.
● Uniform temperature distribution within the furnace.
● Short start-up time.
● The total equipment length can be made shorter.
Main applications
● Brazing of aluminum made heat exchangers and functional components.
Main specifications
● Maximum Temperature: 620℃
● Atmosphere: Nitrogen
● Capacity: Laboratory scale up to a large mass production scale.

Oxynon®Stainless steel brazing Furnace

E-GRB-SUB

Features
● Furnace inner oxygen partial pressure can be lower than 5 ppm.
● Lesser evaporation of metal due to normal atmospheric pressure inside the furnace
　 (No loss of Chromium).
● The C/C composite belt enables continuous conveyance and heat treatment at high
　 temperatures where a metal belt can not be used.
● Heat treatment in innert furnace atmospheres (argon or nitrogen) with no risk of explosion.
● Uniform temperature distribution within the furnace.
● Possible to optimize debinding process and exhaust gas treatment.
● Possible to reduce running costs by use of C/C composite belt.
● In-house laboratory furnace is available for clients' preliminary study of production
　 requirements (fee based).
Main applications
● Brazing of stainless steel heat exchangers
● EGR coolers
● Stainless steel products
Main specifications
● Maximum Temperature: 1250℃
● Atmosphere: Nitrogen, Argon
● Capacity:　Laboratory scale up to a mass production scale

Oxynon®Steel brazing Furnace

E-GRB-REF

Features
● Furnace inner oxygen partial pressure can be lower than 5 ppm.
● Lesser evaporation of metal due to normal atmospheric pressure inside the furnace
　 (No loss of Chromium).
● Use of the C/C composite belt provides continuous conveyance and heat treatment
　 up to 2500℃.
● Heat treatment in inert furnace atmospheres (argon or nitrogen) with no risk of explosion.
● Uniform temperature distribution within the furnace.
● Shorter processing time.
● Possible to optimize debinding process and exhaust gas treatment.
● No risk of decarburizing.
● Possible to reduce running costs by use of C/C composite belt.
● In-house laboratory furnace is available for clients' preliminary study of production
　 requirements (fee based).
Main applications
● Brazing of torque convertors and high carbon content steel materials.
Main specifications
● Maximum Temperature: 1150℃
● Atmosphere: Nitrogen
● Capacity: Laboratory scale up to a mass production scale.
